Motorized Roman Shade
ATF35-RS
- Exceptionally compact motorized roman shade.
- Suitable for most ordinary windows.
(Max. dimensions: 2000 mm or 79" in width, 3000 mm or 118" in height and max. square: 6 m2 or 7.2 yd2) - Switch operation type and FM remote type are available.
Feature
- 01
-
This compact design motorized roman shade offers a variety of uses:from commercial to home.
- 02
-
ATF35 tubular motor realizes quiet operation. (less than 40 dB)
- 03
-
A good choice for a wide range of home and commercial settings.
- 04
-
Motor for switch operation and motor (built-in FM Receiver) are available.
Details
Motor Specifications
| Power Source Voltage | V | AC220 - 230 |
|---|---|---|
| Frequency | Hz | 50 / 60 |
| Current | A | 0.485 |
| Power Consumption | W | 115 |
| Rated Torque | Nm | 4 |
| Rated RPM | rpm | 23 |
| Rated Running Time | min | 4 |
| Ambient Temperature | ℃ | -10 to 40 |
- Since this is not synchronized motor, RPM is vary depending on fabric weight.
